MSI PRO A520M-A PRO DDR4 AM4 Micro-ATX Motherboard

Name: MSI PRO A520M-A PRO DDR4 AM4 Micro-ATX Motherboard
Brand: MSI
SKU: TN-10102
Price: 19999 PKR
Availability: OutOfStock

Manufacturer's page

1 / 4

19,999PKR

Out of stock

Ask about it on WhatsApp

10 Months Local Warranty

Keep your invoice to claim

Official store

Direct from brands

Specifications

LAN: 1Gb Ethernet
Audio: Realtek ALC892/ALC897 7.1 HD Audio
Brand: MSI
Model: PRO A520M-A PRO
Chipset: AMD A520
RAM Type: DDR4
Warranty: 10 Months Local Warranty
M.2 Slots: 1 x M.2 (PCIe 3.0 x4)
RAM Speed: DDR4 (Depends on CPU, up to ~4600 MHz OC typical)
USB Ports: • Rear: 4 x USB 3.2 Gen1 Type-A • Rear: 2 x USB 2.0 • Front: 2 x USB 3.2 Gen1 Type-A • Front: 4 x USB 2.0
CPU Socket: AM4
PCIe Slots: 1 x PCIe 3.0 x16 1 x PCIe 3.0 x1
SATA Ports: 4 x SATA III
Form Factor: mATX
RGB Support: No
Memory Slots: 2 x DIMM
PCIe Version: PCIe 3.0
RAM Capacity: 64 GB
Supported CPUs: AMD Ryzen Processors (AM4 Platform)
Graphics Output: 1 x HDMI 1 x DVI-D
Cooling Features: Basic Heatsink Design + Fan Control
Internal Headers: • 1 x 24-pin ATX Power • 1 x 8-pin CPU Power • 1 x CPU Fan Header • 1 x System Fan Header • 1 x TPM Header • 1 x Front Panel Header • 1 x Front Audio Header
Wireless Connectivity: No

19,999PKR

Out of stock

Ask about it on WhatsApp

10 Months Local Warranty

Keep your invoice to claim

Official store

Direct from brands

About this product

The MSI PRO A520M-A PRO DDR4 AM4 mATX Motherboard is a reliable and budget-friendly solution designed for everyday computing and entry-level builds. Powered by the AMD A520 chipset, it supports a wide range of AMD Ryzen processors on the AM4 socket, making it a solid choice for office systems and basic gaming setups.

With dual-channel DDR4 memory support up to 64GB, the MSI PRO A520M-A PRO DDR4 AM4 mATX Motherboard ensures stable multitasking performance. It includes essential expansion options like a PCIe 3.0 x16 slot for graphics cards and an M.2 slot for fast NVMe storage, along with 4 SATA ports for additional drives.

Connectivity is practical with multiple USB 3.2 Gen1 and USB 2.0 ports, while display outputs like HDMI and DVI-D provide flexibility for integrated graphics usage. Built with durability in mind and equipped with core features like TPM support and RAID capability, this motherboard delivers dependable performance for cost-effective PC builds.

Specifications

LAN

1Gb Ethernet

Audio

Realtek ALC892/ALC897 7.1 HD Audio

Brand

MSI

Model

PRO A520M-A PRO

Chipset

AMD A520

RAM Type

DDR4

Warranty

10 Months Local Warranty

M.2 Slots

1 x M.2 (PCIe 3.0 x4)

RAM Speed

DDR4 (Depends on CPU, up to ~4600 MHz OC typical)

USB Ports

• Rear: 4 x USB 3.2 Gen1 Type-A • Rear: 2 x USB 2.0 • Front: 2 x USB 3.2 Gen1 Type-A • Front: 4 x USB 2.0

CPU Socket

AM4

PCIe Slots

1 x PCIe 3.0 x16 1 x PCIe 3.0 x1

SATA Ports

4 x SATA III

Form Factor

mATX

RGB Support

Memory Slots

2 x DIMM

PCIe Version

PCIe 3.0

RAM Capacity

64 GB

Supported CPUs

AMD Ryzen Processors (AM4 Platform)

Graphics Output

1 x HDMI 1 x DVI-D

Cooling Features

Basic Heatsink Design + Fan Control

Internal Headers

• 1 x 24-pin ATX Power • 1 x 8-pin CPU Power • 1 x CPU Fan Header • 1 x System Fan Header • 1 x TPM Header • 1 x Front Panel Header • 1 x Front Audio Header

Wireless Connectivity
